ROUGHNESS | FINISH

What can we do?

• One second Ra measurement

• Any materials or surface complexity (3D or 2D)

• Automotive roughness finish standards

ROUGHNESS | FINISH ANALYSIS

• Ra | Sa profile & surface average roughness

• Rq | Sq profile & surface rms roughness

• Rz | Sz maximum height

• Sp | Sv maximum peak & pit height

• SKu | Ssk kurtosis & skewness of height distribution

• Bearing ratio & index

• Sk kernel roughness depth

• Spk | Svk reduced peak height & valley depth

• Sr1 | Sr2 upper & lower material ratio

• Sci & Svi core & valley fluid retention index

AND MORE

TESTING STANDARDS

ISO 25178, ISO 4287, ISO 13565
ASME B46.1
Includes: GB/T, DIN, JIS, NF, BSI, UNI, UNE ISO equivalents

* Instrument parameter limits may differ from those specified within the standard.
