PROFILOMETRY

LAB SERVICES & CONSULTING

NANOVEA Profilometry Lab Services offer surface profiling capabilities to measure the surface roughness, surface finish, surface profile, surface texture and more.

Our laboratory services are performed using Chromatic Confocal technology using NANOVEA non-contact profilometers. Chromatic Confocal technology uses wavelengths of light that can accurately determine physical height to measure surface texture and its features. Our technology enables measurements of samples in seconds, regardless of geometric complexity, size or material type: transparent and opaque, low to high reflectivity, smooth to rough texture, and step heights from nanometers to millimeters all without scratching or damaging the sample. Our equipment can provide the characteristics of a material’s surface variation per a given standard and specification ranging from ASTM and ISO standardized testing to custom solutions for your application.

NANOVEA has been redefining international standards in quality control and materials engineering for over two decades. This unmatched in-depth experience we have acquired throughout all industries and applications is now available to you in the form of lab testing services and personal consultations.

PROFILOMETRY

2D & 3D NON-CONTACT CHROMATIC LIGHT

ALL SURFACES & MATERIALS

Surface Roughness

Geometry Analysis

Step Height & Thickness

Flatness & Warpage

Texture Analysis

Volume & Area

Surface Subtraction

R-values & S-values

STANDARD

ISO 4287

ISO 13565

ISO 12085

ISO 12780

ISO 12181

ISO 25178

and other ISO & ASME standards

No Sample Preparation

No Refocusing Required

Analyze Any Surface

Easy to Use

2D & 3D SURFACE PROFILING

ROUGHNESS & FINISH

TEXTURE & GRAIN

GEOMETRY & SHAPE

VOLUME & AREA

FLATNESS & WARPAGE

STEP HEIGHT & THICKNESS

NANOVEA

PROFILOMETERS

NANOVEA Profilometers are 3D, non-contact surface profiling systems designed with Chromatic Confocal technology, which uses wavelengths of light to accurately determine physical height. NANOVEA optical profilometer models include Fully Portable Profilometers, Compact Profilometer, Large Area Profilometers and Superior Stability Profilometer.

With a single profilometer scan, a wide range of measurements can be obtained such as 3D waviness, roughness, step height and/or film thickness to advanced fractal analysis and microstructure/particle characterization.

Chromatic Confocal technology uses white light that passes through a series of lenses with high degree of chromatic aberrations. Each wavelength will focus at a different distance creating the vertical measurement range. When a surface of interest is within the measurement range a single wavelength of the white light will be in focus while all others will be out of focus. Only the focused wavelength will pass through the pin hole filter to reach the CCD spectrometer. The physical wavelength measured corresponds to a vertical position.

PROFILOMETER OPTIONS

Portable

Compact

Portable

High Speed

Modular

Standard

Modular

Large area

Large Area

Stability

NANOVEA designs and manufactures instruments for materials testing and quality control.

Our Profilometers, Tribometers and Mechanical Testers can be found in renowned education and industrial organizations around the world.

For over 25 years, researchers and companies dealing with the most demanding applications have been relying on our unmatched range of consulting and materials testing services.

PROFILOMETERS

Chromatic Light technology for highest accuracy on any surface, any material.

MECHANICAL TESTERS

The highest accuracy and repeatability with the lowest cost of ownership.

TRIBOMETERS

Highly accurate and repeatable wear and friction testing.

Want us to test your samples?

Please fill up our form and we will reach out to you soon!
