Profilometry · Step height & thickness

Step Height & Thickness Measurement

Step height measurement finds the height difference between two levels of a surface, such as a coating edge, an etched feature or a machined shoulder. Thickness measurement maps how that difference varies across a part. NANOVEA chromatic confocal profilometers also measure transparent films and coatings directly, by detecting both the top and bottom interfaces of the layer.

3D map of a step height measured with a NANOVEA optical profilometer

At a glance

Step height
Point-to-point and point-to-plane steps, with maximum, minimum and mean heights.
Thickness maps
2D or 3D map of thickness over the measured area, with a thickness distribution curve.
Transparent layers
Measures through transparent materials, detecting the top and bottom surfaces of a film or coating.
Resolution
Vertical resolution down to 1.9 nm with fine single-point sensors.
Coverage
Continuous scanning without stitching, so steps can be referenced across large areas.
Any surface
Reflective, transparent, dark or soft materials, without contact.

What step height and thickness tell you

Coating thickness, etch depth, deposit height, tread depth, film uniformity: many quality questions come down to a height difference between two levels. Step height measurement quantifies that difference at a point or along a line; thickness mapping shows how it varies over the whole part, revealing non-uniform deposition, edge build-up or thinning.

Measuring a step

A scan across the step produces a profile or 3D map containing both levels. Two approaches are common:

  • Point-to-point: the height between two selected points. Quick, but sensitive to roughness at those points.
  • Point-to-plane: a reference plane is fitted to one level and the other level is measured relative to it. Averaging over many points makes this more repeatable on rough or textured surfaces.

Over an area, the analysis reports maximum, minimum and mean step heights, so a single representative value is backed by its spread.

Measuring through transparent layers

Chromatic confocal sensors have a capability that many surface-measurement techniques lack: they can measure through transparent materials. Because each wavelength focuses at a different height, light reflected from the top of a transparent film and from the interface beneath it appears as two separate signals. Their separation, corrected for the layer’s refractive index, is the film thickness. This measures coating and film thickness directly, without masking, cutting a step or touching the layer, and builds full 2D and 3D thickness maps with a thickness distribution curve.

Calibration and confidence

Step-height results are only as good as the vertical scale behind them. Certified step-height standards, the material measures described in ISO 5436-1, are used to verify that scale. Fine single-point sensors resolve height down to 1.9 nm, and the choice of sensor sets the balance between vertical resolution and measurement range for each application.

Large areas without stitching

When a step must be referenced across a large part, such as gridlines on a solar cell, a coating edge along a panel or tread depth across a tire, stitched measurements introduce height offsets between tiles that corrupt the result. Continuous chromatic confocal scanning keeps one consistent height reference across the whole scan.

Standards

StandardScope
ISO 5436-1Measurement standards: material measures (including step-height standards)

Certified step-height artefacts used to calibrate and verify the vertical scale of the profilometer.

ISO 25178-2Areal surface texture: terms, definitions and surface texture parameters

Areal height parameters of the surfaces on either side of the step.

Instrument parameter limits may differ from those specified within each standard.

From the same 3D scan

Instruments that run this test

Every instrument is built to order. Send us your samples and we run your test in our laboratory first, then configure the instrument around the result.

Published results

Measured in our own laboratory, on the instruments we design and build, and published with full test parameters.

All profilometry application notes →

Independent published research

NANOVEA instruments appear in 4 published studies on step height and thickness, by researchers at universities and industrial laboratories worldwide.

All 4 studies →

NANOVEA materials testing laboratory

Need step or thickness data? Send us your samples.

Our laboratory measures step heights, coating thickness and form on the same profilometers we build, and reports results with the full measurement settings.

Your samples are tested by the people who design the instruments, so you get advice on the method as well as the numbers.

Surface profiling lab services

Frequently asked questions

How is step height measured with a profilometer?

The surface is scanned across the step, and the height difference is calculated between reference regions on each side. Point-to-point measures between two chosen points; point-to-plane fits a plane to one level and measures the other relative to it, which averages out roughness and is more repeatable. Maximum, minimum and mean step heights can be reported over an area.

Can the thickness of a transparent coating be measured without a step?

Yes. A chromatic confocal sensor focuses different wavelengths at different heights, so light reflected from both the top surface and the underlying interface of a transparent layer produces two signals. The separation gives the layer thickness, corrected for the material's refractive index. No step or masking is needed.

What is a thickness map?

A 2D or 3D map showing how coating or film thickness varies across the measured area, with a distribution curve summarising it. It reveals thinning at edges, streaks, voids and non-uniform deposition that a single-point thickness reading would miss.

How is the vertical scale of a profilometer verified?

With certified step-height standards (material measures as defined in ISO 5436-1). Measuring a known step confirms the vertical calibration of the sensor before or alongside sample measurements.

Why measure step height without contact?

A stylus can deform or scratch soft films, photoresists and polymers, and its tip shape rounds off sharp step edges. Non-contact optical measurement leaves the sample intact and measures transparent, reflective and soft layers equally well.
